ALUMINUM WINDOWS

T8700HW Series |
4” Thermally-Broken Projected Heavy Wall Window

The D8 Aluminum T8700HW Series Thermally-Broken Projected Heavy Wall Window provides exceptional value and performance while enhancing the views of schools, hospitals, public buildings or any commercial application. This system is engineered to meet DOD/GSA blast criteria and ASTM criteria for hurricane-rated systems.

The T8700HW Series Thermally-Broken Projected Heavy Wall Window has been tested in accordance with AAMA/WDMA/CSA/101/I.S.2/A440-08 (NAFS-08) and comes with an industry standard factory warranty.

Features

Results

Blast rated Engineered to meet DOD/GSA blast criteria
Hurricane rated Engineered to meet ASTM 1886/ASTM 1996
4” depth Delivers structural integrity to accommodate design requirements
Heavy wall Design flexibility to accommodate increased size and performance requirements
Casement, awning and fixed configurations Options to accommodate design intent
Custom painted and anodized finishes Wide variety of finishes to accommodate design specifications and customer needs

Performance Data

Type Fixed Awning Casement
Air @ 6.24 PSF  |  Per ASTM E-283 <0.01 cfm/SF 0.01 cfm/SF 0.01 cfm/SF
Water  |  Per ASTM E-331 12 psf 10 psf 10 psf
U-Value  |  Per NFRC-100 0.39 - 0.58 0.50 - 0.65 0.50 - 0.65
